The perfect size loudspeaker for any room. The most compact Aspen yet — a true full-range 3-way that covers 30Hz to beyond 20kHz with grace, dynamics, slam, and low distortion, and works in any small to medium-sized room. The culmination of 50 years of PS Audio experience, with woofers, radiators, tweeters, and midranges designed from scratch. In all respects, the FR10 will transcend your expectations of what a small floor-standing loudspeaker can do.

Design

The FR10 joins the ranks of a rare handful of true full-range speakers that can honestly cover 30Hz to beyond 20kHz with grace, dynamics, slam, and low distortion — and work in any small to medium-sized room. Grace, beauty, PRaT, power, and a musicality that is rare amongst six-figure offerings from other manufacturers await owners of the Aspen FR10. That this speaker is financially within reach of many makes it a miracle.

Application

Loudspeakers are part of the family. The Aspen FR10 is designed to more easily fit into any living environment and perform at its best with a minimum of setup hassles and a maximum of options. While the FR10, like all high-performance speakers, appreciates some breathing room from the front wall, placement is a snap. Using the included step-by-step guide and CD, setup — from unboxing to playing music — happens easily in a few short hours.

Overview

The FR10 will fit into every small to medium-sized room and provide room-shaking bass down to 30Hz. For the upper end, it employs the same Aspen planar tweeter found in both the FR20 and FR30, and for its legendary open midrange it relies upon the same planar technology as its bigger counterparts. Without question, the Aspen FR10 is the perfect loudspeaker for any room and budget.

The Drivers

On the FR10 we chose a technology with the speed of an electrostat and the dynamics of a cone: planar magnetics. These ultra-low-distortion drivers are driven by front and rear magnetic structures for inherent linearity, with none of the cone or dome breakup, inductance modulation, or hysteresis distortion that plagues traditional drivers. For the low end, long-throw high-excursion 6.5″ woofers with a split magnetic gap, double Faraday ring, and Rohacell foam-core cones are paired with three rear-mounted high-compliance passive radiators for deep, port-free bass.

The Enclosure

The Aspen FR10 enclosure starts with the internal structure necessary for great sound and is then lovingly sculpted into a work of art, with industrial design by Studio 63. Internally, it is extensively braced to minimize colorations. The main body is built with MDF, while the sculpted front baffle is formed from a dense, rigid, well-damped thermoset fiberglass resin composite with integrated high-frequency waveguides. It is finished in 20 coats of hand-rubbed high-grade lacquer atop a sturdy milled aluminum base.

Specifications

• Colors: Satin White, Satin Black · 3-way, passive radiator (three 6×9″ rear-firing)
• Tweeter: 2.5″ planar magnetic · Mid: 8″ planar magnetic · LF: 2 × 6.5″ woofers
• Crossover: 550 Hz, 1750 Hz — LR 4th order
• Sensitivity: 86.5 dB · Impedance: 4Ω (3.3Ω min) · Recommended Power: 50–200W
• Frequency Response: 32Hz–20kHz (-6dB) half space; 25Hz (-6dB) in-room
• Dimensions: 41.5″ × 11.75″ × 16.25″ with base · Weight: 75 lbs (34.1 kg)
